BCD-To-Decimal Decoders/Drivers (74154)

Name: BCD-To-Decimal Decoders/Drivers (74154)
SKU: JHJJ7034597591
Availability: InStock

$6.00 ~~$13.00~~

Review

DescriptionEach of these 4-line-to-16-line decoders utilizes TTL circuitry to decode four binary-coded inputs into one of sixteen mutually exclusive outputs when both the strobe inputs, G1 and G2, are LOW. The demultiplexing function is performed by using

Satisfaction 100% Guaranteed
Free shipping on orders over $30
60 day easy Return

SKU: JHJJ7034597591 Category: Factory Direct

Description
Reviews (0)

Description

Each of these 4-line-to-16-line decoders utilizes TTL circuitry to decode four binary-coded inputs into one of sixteen mutually exclusive outputs when both the strobe inputs, G1 and G2, are LOW. The demultiplexing function is performed by using the 4 input lines to address the output line, passing data from one of the strobe inputs with the other strobe input LOW. When either strobe input is HIGH, all outputs are HIGH. These demultiplexers are ideally suited for implementing high-performance memory decoders. All inputs are buffered and input clamping diodes are provided to minimize transmission-line effects and thereby simplify system design.
