74LS107 (Dual JK flip-flop)

Description

Description

The ‘107 contain two independent J-K flip-flops with individual J-K, clock, and direct clear inputs. The ‘107 is a positive pulse-triggered flip-flop. The J-K input data is loaded into the master while the clock is high and transferred to the slave and the outputs on the high-to-low clock transition. For these devices the J and K inputs must be stable while the clock is high.

Specifications

• Channels (#) 2
• Technology Family LS
• VCC (Min) (V) 4.75
• VCC (Max) (V) 5.25
• Input type TTL
• Output type TTL
• Clock Frequency (MHz) 30
• ICC (Max) (uA) 6000
• IOL (Max) (mA) 8
• IOH (Max) (mA) -0.4
• Features Negative edge triggered, High speed (tpd 10-50ns), Clear
