Description
Specifications
- Transmitter module size: length 17mm width 11mm height 2.5mm
- Receiver module size: length 24mm width 10mm height 5.5mm
- Transmitting and receiving coil size: outer diameter 38mm inner diameter 28mm thickness 1.3mm
- Connection method: 1 pin connected to the negative pole of the power supply; 2 feet connected to the positive pole of the power supply; 3 and 4 feet connected to the external transmitting coil
- Transmitter module working voltage: 5V~12V
- Transmitter module operating current: automatically increase or decrease with the receiving load current
- Maximum output current of the receiving module: 2A
- Transmitting distance: 1~20m
