The 4-digit 7-segment display (5461BS-1) is a compact numeric display module designed for digital readout applications. It features a common anode configuration with bright red LEDs and a 0.56 inch digit height for clear visibility. The module operates at approximately 1.99 V per segment and supports multiplexed control for efficient pin usage. Built for stable and consistent performance, it is suitable for integration with microcontrollers and driver ICs. Ideal for clocks, counters, meters, and embedded system displays.
Features
- Common anode LED configuration
- Four-digit numeric display module
- 0.56 inch digit height for clear visibility
- Red LED segments with high contrast output
- Forward voltage around 1.99 V per segment
- Compatible with multiplexing control techniques
- Standard pin spacing for PCB integration
- Low power consumption per segment
- Suitable for driver ICs like TM1637 or MAX7219
- Uniform brightness across all segments
- Fast response time for dynamic display updates
- Durable epoxy package construction
- Easy interfacing with microcontrollers
- Clear segment separation for accurate digit display
Specifications
- Display Type: 4-digit 7-segment LED
- Configuration: Common Anode
- Part Number: 5461BS-1
- Digit Height: 0.56 inch (14.2 mm)
- LED Color: Red
- Forward Voltage (Per Segment): 1.82.2 V
- Forward Current (Per Segment): 1020 mA
- Peak Forward Current: 30 mA
- Wavelength: 620630 nm
- Viewing Angle: 60
- Power Consumption: Low power LED operation
- Operating Temperature: -20C to +70C
- Storage Temperature: -30C to +80C
- Mounting Type: Through-hole
- Pin Count: 12 pins
